|
Product Details:
|
| Specs: | 50g/tube | Package Material: | Aluminum |
|---|---|---|---|
| Trademark: | Desofin | Dosage: | 3 Tubes For One Ton |
| Product Name: | Desofin Low Pressure Casting Additive | Application: | B2 Alloy |
| Highlight: | B2 alloy Desofin,Desofin 50g Per tube,50g Per Tube Brass Casting Additive |
||
| Form of product | 50g/capsule, can be put into the cooper melt together with the sealing aluminum capsule packing while being used. |
| Consumption | 150 grams capsule for each 1metric ton of melted brass or melted alloy |
| Alloy requirements | ◆ Suitable for all copper alloy, including pure copper (99.85%) |
| ◆ Work best on brass alloy | |
| ◆ Can be used to lower the casting temperatures and increase the castability and fluidity of the aluminum bronze, red brass and tin bronze. | |
| ◆ Also proper for aluminum high pressure casting, parts will come out bright and shiny |
| Alloy Class and General Parameters |
Dosage |
Expected Results
|
Special Instructions | ||
| Grain Refinement | Deoxy-dation | Reduced Casting Temp. | |||
| Yellow Brass (Over 17% Zn. Sn less than 6%. Under 2% total Al, Mn. Ni, Fe, Si. Pb less than 0.5%.) |
150 grams per metric ton (5 grams per 100 lb.) |
YES |
YES |
YES |
Grain refinement occurs when copper content is between 57 and 63 percent. Optimal grain refinement occurs when copper content is 59.5 percent and aluminum content is 0.6 percent. See Notes 1 and 2. |
| Leaded Yellow Brass (Over 17% Zn. Sn less than 6%. Under 2% total Al, Mn. Ni, Fe, Si. Pb more than 0.5%.) |
150 grams per metric ton (5 grams per 100 lb.) |
YES |
YES |
YES | |
| High Strength Yellow Brass (Manganese Bronze) (Over 17% Zn. Over 2% total Al, Mn. Sn, Ni, Fe. Si less than 0.5%. Pb less than 0.5%. Sn less than 6%) |
50 grams per metric ton (5 grams per 100 lb.) |
May reduce grain if Sn + Fe is less than 0.5% |
YES |
YES | |
Red Brass (2% to 8% Zn. Sn less than Zn. Pb under 0.5%) |
200 grams per metric ton (9 grams per 100 lb.) |
NO |
YES |
YES | Use without AL tubes. Add to transfer ladle along with phos copper. If high oxygen occurs, add Mn before adding DesofinTM. |
Aluminum Bronze (Al 5% to 15%. Fe up to 10% - with or without Mn or Ni. Si less than 0.5%) |
200 grams per metric ton (18 grams per 100 lb.) |
NO |
YES |
YES |
If high oxygen occurs, add Mn before adding DesofinTM. |
Tin Bronze (Sn 2% to 20%. Zn less than Sn. Pb under 0.5%) |
200 grams per metric ton (9 grams per 100 lb.) |
NO |
YES |
YES |
Use without Al tubes. Add to transfer ladle along with phos copper |
| Notes: 1. If Sn + Fe is greater than 0.5%, intermetallic compounds will form that will leave "comet tails" when casting is polished. 2. Miller & Englehardt Co., lltd recommends use of "B-2" yellow brass alloy with DesofinTM for permanent molding applications. B[1]2 alloy composition: Cu 59.5 to 61.5%; Pb 0% to 3.0%; Al 0.5% to 0.7%, Ni 1%; Sn + Fe 0.5 % max, Mn 0.02% max, Si 0.02% max, Zn balance. | |||||
Form of product :50g/capsule
Applied for B2 alloy
Melting method, by dipping in the copper bath
The final perfect brass-cup
Contact Person: Hera Huang
Tel: 13220942308
Fax: 86-0532-8099-3622
