Natural Graphite Powder Expandable Graphite For Plastic

Large Image : Natural Graphite Powder Expandable Graphite For Plastic

Product Details:

Place of Origin:	Qingdao of China
Brand Name:	Hensen
Model Number:	HS

Payment & Shipping Terms:

Minimum Order Quantity:	20 GP Container
Price:	USD$500/TON-USD$3000/TON
Packaging Details:	Small bag into big bag total 20 tons for 20' feet container
Delivery Time:	30 working days
Payment Terms:	T/T
Supply Ability:	3000 ton per month

Contact Now

Natural Graphite Powder Expandable Graphite For Plastic

Description

Carbon Content:	HIGH-CARBON	Shape:	Expandable Graphite Powder
Product Name:	Expandable Graphite	Size:	+80mesh
Type:	Natural	Purity:	≥95%
Related Industry:	Flame Retardant	Package:	As Customer's Request
Highlight:	Battery Artificial Graphite Powder , Artifical Expandable Graphite Powder , 80mesh Expandable Graphite

Natural Graphite Powder Expandable Graphite For Plastic

Expandable Graphite

Expandable graphite is a synthesized intercalation compound of graphite that expands or exfoliates when heated. Once heated, it results an increase in the volume of up to 400 times, a lowering of bulk density, and approximately a 10-fold increase in surface area. Then it’s compressed into a highly cohesive flexible sheet.
Another principal application is as a flame retardant. As a result of the heat of a fire the graphite expands and creates an intumescent layer on the surface of the material. This retards the spread of fire and minimizes one of the most harmful effects of combustion: the creation of toxic gases and fumes.

Benefits of expandable graphite as flame retardant:

1. Forms an intumescence layer with Thermal Radiation Shielding, with superior Heat Diffusion.
2. Stops or slows the spread of fire and toxic gases.
3. Easy to apply, cost Effective, satisfied performance with low adding levels.
4. Non-toxic, non-halogenated fire-stop additive.
5. Neutral surface pH makes compatible with any catalyst system.

Typical Grades

Grade Name	Mesh	Expansion Ratio (cc/g)	Purity (%)	Moisture (%)	PH	Sulfur (ppm)	Onset Temp (°C)	Application
HS555	+50	250:1	95-97	<1	6-9	*	160-180	PU foam, Bituman.
HS855	+50	250:1	98-99	<1	6-9	*	160-180	PU foam, Bituman.
HS955	+50	250:1	99-99.5	<1	6-9	*	160-180	PU foam, Bituman, for application require least instruments damage.
HS085	+80	250:1	90-95	<1	6-9	*	160-180	PU foam, EPS foam, XPS foam, sealing strip.
HS585	+80	250:1	95-97	<1	6-9	*	160-180	PU foam, EPS foam, XPS foam, sealing strip.
HS055	+50	250:1	90-95	<1	6-9	*	160-180	PU foam, EPS foam, XPS foam, sealing strip.
HS988	+80	180:1	99-99.5	<1	6-9	<1500	*	Graphite foil, roll, gaskets.
HS980HP	+80	200:1	99.5-99.8	<1	6-9	<1500	*	Graphite foil, roll, gaskets.
HS980UHP	+80	200:1	>99.9	<1	6-9	<1500	*	Battery.
HS557	+50	270:1	95-97	<1	6-9	*	160-180	Steel oxygen protection.
HS611	-100	100:1	96-98	<1	6-9	*	160-180	Fireproof textile.
HS223	-200	30:1	92-95	<1	6-9	*	160-180	Thin coating.
HS5HE	+50	350:1	95-97	<1	6-9	*	160-180	Collar pillar.
HS9HE	+50	350:1	99-99.5	<1	6-9	*	160-180	Collar pillar, for application require least instruments damage.
HS558HT	+50	180:1	95-97	<1	6-9	*	220	Mixing, extruding or processing at higher temperatures. Used as fire-retardant additive in PE, PP, and HIPS.
HS558UHT	+50	180:1	95-97	<1	6-9	*	250	Processing temperatures are very high. Used as fire-retardant additive in PE, PP, and HIPS.
