95%-99% Carbon Fixed Micronized Graphite Powder , Industry Natural Expandable Graphite
Place of Origin:
Qingdao
Brand Name:
Hensen
Minimum Order Quantity:
20Ton
Price:
USD500/T-USD2000/T
Packaging Details:
Jumbo bag 20 tons for 20 feet container
Delivery Time:
30 working days
Payment Terms:
T/T
Supply Ability:
1000Tons per Monthe
Inquiry Now
Get A Quote
Specifications
Highlight Features
Industry Natural Micronized Graphite Powder
,95% Carbon Fixed Expandable Graphite
,99% Carbon Fixed Expandable Graphite
Fixed Carbon:
95%-99.9%
Color:
Silver Grey
Purity:
99.9%Min
Size:
10-100UM
Sample:
Free
Procuct Name:
Natural Graphite
Product Description
Product Description:
95%-99% Carbon Fixed High Quality Micronized Graphite Powder Industry Natural Expand
Micronized graphite is natural crystalline graphite ,subjected to milling ,grinding ,and particle classification:then further
concentrate to desired levels .Hensen's micronized graphite's average particle size ranges from 3 to 60 microns ,with fixed
carbon of 90-99.9% .Using one or combination of different mills ,such as jet mill,hammer mill and spherical mill,Hensen
Graphite produces and supplies micronized graphite with specific physical properties and optimized to the needs of each application .
Variety: FS.F Specification: particle size 1-38μm
Properties: It has oxidation resistance, self-lubrication and isoplasticity under high temperature conditions, and has good
electrical conductivity, electric heating and adhesion.
Typical Grades :
| Grade |
D10 (UM) |
D50 (UM) |
D90 (UM) |
Carbon Content (%) | Bulk Density(g/l) | Moisture(%) |
| HSMG35 | 15±5 | 35±5 | 70±10 | 95-99 | 550-600 | <0.5 |
| HSMG25 | 7±3 | 25±5 | 60±10 | 95-99 | 350-450 | <0.5 |
| HSM20 | 6±3 | 20±5 | 38±8 | 95-99 | 300-400 | <0.5 |
| HSMC10 | 4±1.5 | 10±2 | 25±6 | 95-99 | 200-300 | <0.5 |
| HSMG6BP | 3±1 | 6±1.5 | 22±5 | 95-99 | 100-170 | <0.5 |
| HSMG4 | 2±1 | 4±1 | 11±2 | 95-99 | 130-230 | <0.5 |
| HSMG2 | 1±0.5 | 2±1 | 5±2 | 95-99 | 150-250 | <0.5 |
Application :
Nowadays, graphite is being used in many industries, here just listed 3 types for a general understanding of its application:
1: Used as refractory material: Graphite and its products have the properties of high temperature resistance and high strength. It is mainly used
in the metallurgical industry to make graphite crucibles. In steel making, graphite is often used as a protective agent for steel ingots and as a
lining for metallurgical furnaces.
2:Used as conductive material: used in the electrical industry to make electrodes, brushes, carbon rods, carbon tubes, positive electrodes of
positive current devices, graphite washers, telephone parts and coatings for television picture tubes.
3: Used as wear-resistant lubricating material: Graphite is often used as a lubricant in the machinery industry. Lubricating oil often cannot be
used under high-speed, high- temperature, and high-pressure conditions, while graphite wear-resistant materials can work at high sliding
speeding at a temperature of 200-2000 celcius degree without lubricating oil. Many equipment that transports corrosive media widely use
graphite materials to make piston cups, seals and bearing. They do not need to add lubricating oil during operation.
Package :
About our company :
Since 1985,Hensen Graphite has been proundly serving customers around the globe .
After years of development ,Hensen Graphite owns one mine in Heilongjinag ,four operation factories ,one sales office in Qingdao,and
headquarter in Laixi .
By focusing on meeting our customers needs ,we continue to maintain our position as the supplier of choice for graphite .Hensen Graphite
supplies more than 30,000 MT various kinds of graphite products to a wide range of industrial applications,including fire retardants ,friction
materials ,batteries ,fuel cells ,lubricants ,cast metals ,driling ,paints ,coatings,and plastics.
Since the day of foundation,Hensen Graphite has opened its eyes ,and supplied quality graphite products not only in China,but globally (marked
gray as below ).
